Quadoa Optical CAD Features
Quadoa is the first optical design software that includes multi-sequence optics in addition to sequence, making it suitable for all optical system designs.
02
Quadoa Optical CAD Features
Quadoa® defines the next generation of optical design software, developing Quadoa with a broad and comprehensive range of optical design capabilities with a focus on optical design, analysis, and optimization.Quadoa。
Quadoa Feature
Object-oriented, easy to manage single objects and multiple objects. It is also possible to manage components with the same function through assemblies.
Powerful and easy-to-use optimization methods, even in complex systems, designers can achieve the best design results through global or local optimization.
Instant ghost analysis results are updated, Quadoa provides Live Ghost analysis function, which is an innovative feature that other software does not have.
The off-axis system is easy to set up, providing global coordinates and local coordinates to facilitate the rotation and movement of optical components.
Immediate Tolerance Analysis, for any optical system design, it is important to perform a practical tolerance analysis. Quadoa’s® hierarchical structure allows you to establish the mechanical dependencies of elements and components in your model, fully simulating the real world.
